How to run OpenShift V3 on an existing Kubernetes Cluster

Important Note - this is a very old post and completely outdated

I’m a big fan of Kuber­netes and the ideas it brings to enable run­ning Docker con­tain­ers at scale. How­ever if you’ve used Kuber­netes you’ll know that right now the tool­ing around it is pretty basic from a devel­oper and appli­ca­tion life­cy­cle per­spec­tive. Open­Shift V3 builds on the con­cepts of Docker and Kuber­netes to add some much needed higher level tool­ing and a Web UI that is really nice.

Here are just a few of the fea­tures that Open­Shift Ori­gin pro­vides out of the box on top of a Kuber­netes cluster:

• A rich set of role based poli­cies out of the box
• Quota’s and resource limits
• Source to Image — no need to know Docker, just build an image very effi­ciently from source
• Auto­mated builds using on webhooks
• Appli­ca­tion focused CLI, including:
• Get logs for any of your run­ning containers
• Clever port for­ward­ing for remote debugging

One of the things I wanted to do was to run a Kuber­netes clus­ter in Google Con­tainer Engine but run Open­Shift on top of it. This is because Con­tainer Engine does a great job of run­ning my Kuber­netes clus­ter — includ­ing han­dling autoscal­ing based on demand, net­work­ing and per­sis­tent vol­umes inside the clus­ter etc. All the plumb­ing stuff I don’t want to have to care about when run­ning a cluster.

When I looked into it I found this exam­ple of run­ning OpenShift-Origin as a pod in an exist­ing Kuber­netes clus­ter in the Kuber­netes GitHub project, how­ever it didn’t work! So this is my basic guide in how to setup Open­Shift V3 Ori­gin to run on top of an exist­ing Kuber­netes cluster.

Like all things we do I’m stand­ing on the shoul­ders of giant’s and this tuto­r­ial was of course orig­i­nally writ­ten by Derek Carr in the Kuber­netes exam­ples folder I’ve just tarted it up a bit.

Step 0: Prerequisites

This exam­ple assumes that you have an under­stand­ing of Kuber­netes and that you have forked my exam­ple repos­i­tory.

The Kuber­netes Get­ting Started Guide lists a few options, how­ever for sim­plic­ity and robust­ness I’d rec­c­om­mend using Google Con­tainer Engine to run your Kuber­netes Cluster.

Open­Shift Ori­gin cre­ates priv­i­leged con­tain­ers when run­ning Docker builds dur­ing the source-to-image process.

If you are fol­low­ing the get­ting started guide above and using a Salt based KUBERNETES_PROVIDER (gce, vagrant, aws), you should enable the abil­ity to cre­ate priv­i­leged con­tain­ers via the API.

$ cd kubernetes
$ vi cluster/saltbase/pillar/privilege.sls

# If true, allow privileged containers to be created by API
allow_privileged: true

Now spin up a clus­ter using your pre­ferred KUBERNETES_PROVIDER

$ export KUBERNETES_PROVIDER=gce
$ cluster/kube-up.sh

Per­son­ally I setup my own clus­ter in Google Con­tainer Engine, if you take this approach you will need to fol­low these two guides:

• Quickstart: Deploy an app to a GKE cluster  |  Kubernetes Engine Documentation  |  Google Cloud
• Creating a zonal cluster  |  Kubernetes Engine Documentation  |  Google Cloud

Just one note about this approach — I haven’t tried source-to-image but it may well fail in a vanila Google Con­tainer Engine clus­ter as Google cur­rently doesn’t sup­port cre­at­ing priv­i­leged con­tain­ers via the API.

Whichever way you choose to setup your clus­ter, make sure that kubectl and your ~/.kube/config is setup and can talk to your cluster.

Lets test that our kubectl can talk to the cluster:

$ kubectl get nodes
NAME                               LABELS                                                    STATUS
gke-cluster-1-01678227-node-79jo   kubernetes.io/hostname=gke-cluster-1-01678227-node-79jo   Ready

Next, let’s setup some vari­ables, and cre­ate a local folder that will hold gen­er­ated con­fig­u­ra­tion files.

$ cd openshift-origin-kubernetes-example
$ export BASE=${PWD}
$ export BASE_CONFIG=${BASE}/config
$ mkdir ${BASE_CONFIG}

Step 1: Cre­ate an Exter­nal Load Bal­ancer to Route Traf­fic to OpenShift

An exter­nal load bal­ancer is needed to route traf­fic to our Open­Shift mas­ter ser­vice that will run as a pod on your

Kuber­netes cluster.

$ kubectl create -f $BASE/openshift-service.yaml

Step 2: Gen­er­ate con­fig­u­ra­tion file for your Open­Shift mas­ter pod

The Open­Shift mas­ter requires a con­fig­u­ra­tion file as input to know how to boot­strap the system.

In order to build this con­fig­u­ra­tion file, we need to know the pub­lic IP address of our exter­nal load bal­ancer in order to

build default certificates.

Grab the pub­lic IP address of the ser­vice we pre­vi­ously created.

$ export PUBLIC_IP=$(kubectl get services openshift --template="{{ index .status.loadBalancer.ingress 0 \"ip\" }}")
$ echo "PUBLIC IP: ${PUBLIC_IP}"

Ensure you have a valid PUBLIC_IP address before con­tin­u­ing in the exam­ple, you might need to wait 60 sec­onds in order for it to be setup.

We now need to run a com­mand on your host to gen­er­ate a proper Open­Shift con­fig­u­ra­tion. To do this, we will vol­ume mount our con­fig­u­ra­tion direc­tory and the direc­tory (~/.kube/config) that holds your Kuber­netes con­fig file.

$ docker run --privileged -e KUBECONFIG=/kubeconfig -v ${HOME}/.kube/config:/kubeconfig -v ${BASE_CONFIG}:/config openshift/origin:v1.0.3 start master --write-config=/config --master=https://localhost:8443 --public-master=https://${PUBLIC_IP}:8443

You should now see a num­ber of cer­tifi­cates minted in your con­fig­u­ra­tion direc­tory, as well as a master-config.yaml file that tells the Open­Shift mas­ter how to exe­cute. In the next step, we will bun­dle this into a Kuber­netes Secret that our Open­Shift mas­ter pod will consume.

Step 3: Bun­dle the con­fig­u­ra­tion into a Secret

We now need to bun­dle the con­tents of our con­fig­u­ra­tion into a secret for use by our Open­Shift mas­ter pod.

Open­Shift includes an exper­i­men­tal com­mand to make this easier.

First, update the own­er­ship for the files pre­vi­ously generated:

$ sudo -E chown ${USER} -R ${BASE_CONFIG}

Then run the fol­low­ing com­mand to col­lapse them into a Kuber­netes secret.

$ docker run -i -t --privileged -e KUBECONFIG=/kubeconfig -v ${HOME}/.kube/config:/kubeconfig -v ${BASE_CONFIG}:/config openshift/origin:v1.0.3 cli secrets new openshift-config /config -o json &> ${BASE}/secret.json

Now, lets cre­ate the secret in your Kuber­netes cluster.

$ kubectl create -f ${BASE}/secret.json

NOTE: This secret is secret and should not be shared with untrusted parties.

Step 4: Deploy Open­Shift Master

We are now ready to deploy OpenShift.

We will deploy a pod that runs the Open­Shift mas­ter. The Open­Shift mas­ter will del­e­gate to the under­ly­ing Kuber­netes

sys­tem to man­age Kuber­netes spe­cific resources. For the sake of sim­plic­ity, the Open­Shift mas­ter will run with an embed­ded etcd to hold Open­Shift spe­cific con­tent. Note if the Open­Shift mas­ter fails the etcd con­tent will be lost, this is because etcd is using an ephemeral vol­ume for now.

$ kubectl create -f ${BASE}/openshift-controller.yaml

You should now get a pod pro­vi­sioned whose name begins with openshift.

kubectl get pods | grep openshift  kubectl logs openshift-3a1dt origin I0727 22:11:44.720769 1 start_master.go:307] Starting an OpenShift master, reachable at 0.0.0.0:8443 (etcd: [https://localhost:4001]) I0727 22:11:44.720884 1 start_master.go:308] OpenShift master public address is https://130.211.171.209:8443

Depend­ing upon your cloud provider, you may need to open up an exter­nal fire­wall rule for tcp:8443. For GCE, you can run the fol­low­ing (if you are using Google Con­tainer Engine this should already be done for you):

gcloud compute --project "your-project" firewall-rules create "origin" --allow tcp:8443 --network "your-network" --source-ranges "0.0.0.0/0"

Con­sult your cloud provider’s doc­u­men­ta­tion for more information.

Step 5: Test it out

Open a browser and visit the Open­Shift mas­ter pub­lic address reported in your log, any user­name and pass­word will work as we haven’t con­fig­ured authen­ti­ca­tion yet.

You can use the CLI com­mands by run­ning the following:

docker run --privileged --entrypoint="/usr/bin/bash" -it -e KUBECONFIG=/kubeconfig -v {HOME}/.kube/config:/kubeconfig openshift/origin:v1.0.3 oc help  oc get pods

Or if you have the Open­Shift CLI installed on your local machine you can can skip the docker run com­mand above and just do:

$ oc help
$ oc get pods
